Fashionable and Expandable 18 Square Meters to 60 Square Meters Double-wing Container House Suitable for Residential Use
Product Description:
This double-wing container house breaks the tradition with its innovative design. It adopts a deployable double-wing structure, which greatly expands the living space. The box's appearance is simple and stylish, and the color and shape can be customized according to needs, easily integrated into different residential environments. The internal space layout is reasonable, and the functional divisions are clear, from warm bedrooms to modern kitchens and bathrooms. At the same time, the house has good thermal insulation, waterproof and moisture-proof performance, easy installation, low carbon and environmental protection, bringing a new residential experience that is both creative and practical for residents who pursue a quality of life.
Technical Parameters:
| Top frame main beam |
3.0 bending beam |
| Top frame secondary beam |
40*60*1.5 galvanized square tube |
| Bottom frame main beam |
3.0 bending beam |
| Bottom frame secondary beam |
80*80*2.0 galvanized square tube |
| Flip bottom frame |
2.0 bending parts + 40*60*1.5 square tube |
| Flip wall frame |
2.0 bending parts |
| Flip top frame |
2.0 bending parts |
| Rotate wall frame |
2.0 bending parts |
| Top insulation |
75mm glass wool plus wire mesh |
| Bottom insulation |
0.3mm corrugated veneer + 75mm glass wool |
| Floor |
18mm calcium silicate board + 1.6mm floor glue |
Features:
Low cost: Compared with traditional buildings, container houses do not require a large amount of building materials and complex construction processes, which can save construction costs.
Fast construction speed: Container houses are modular in design. After being prefabricated in the factory, they are transported to the site for assembly. They can be quickly built and completed, greatly shortening the construction period.
Strong mobility: Container houses are easy to transport and relocate, and can be changed at any time as needed, without causing too much waste of resources.
Sturdy and durable: The container adopts a steel structure, has strong earthquake and wind resistance, can withstand large external forces, and has a long service life.
High flexibility: It can be combined and transformed according to different needs, and the internal space can be flexibly arranged to meet various functional requirements.
Applications:
Residential
Commercial
Office
Public Service
Tourism
